- Frame
- Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
- Sizes
- S: 380mm / M: 420mm / L: 450mm / XL: 490mm
- Rear shock
- Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
- Shock settings
- medium compression, medium rebound, air volume spacer 0.2
- Fork
- Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
- Headset
- Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
- Stem
- ONOFF Krypton FG 30mm, CNC, 31.8mm barbore
- Handlebar
- ONOFF Krypton 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
- Grips
- ONOFF Desert, 1lock-on, 135mm
- Seatpost
- ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
- Saddle
- FIZIK Terra Aidon X5 145mm
- Front brake
- Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Rear brake
- Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Brake lever
- Sram DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
- Rims
- Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
- Spokes
- Mavic J-bend double butted, contactless lacing
- Front hub
- Mavic, Boost 15x110mm, IS 6 bolts
- Rear hub
- Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts
- Front tire
- Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
- Rear tire
- Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
- Crankset
- Race Face Aeffect ebike, 165mm
- Rings
- Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
- Chain
- Sram NX Eagle, 12s, Powerlock
- Rear derrailleur
- Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
- Shift levers
- Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
- Casette
- Sram XG-1230, 11-50T, 12s
- Derailleur hanger
- SRAM UDH
- Weight
- 23,9 kg
- Display
- Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller
- Motor
- Bosch Performance Line CX (25km/h) Smart System
- Battery
- Bosch Powertube 750Wh
