חדשאנדורו
על המוצר
מפרט:
- Frame
- Foxy 29 Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, aluminium CSC upper link with carbon bridge, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. *Optional Geometry Kit
- Sizes
- S: 380mm / M: 420mm / L: 470mm / XL: 510mm
- Rear shock
- Fox Float DPX2 LV EVOL Performance, 205x62.5mm. Settings: compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
- Shock setting
- Light compression, extra light rebound, air volume spacer 0.6
- Fork
- Fox 36 29 Float FIT GRIP EVOL Performance, 160mm, tapered steerer tube, 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
- Headset
- Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
- Stem
- Onoff Stoic FG 30mm, 6061 forged alloy, 31.8mm barbore
- Handlebar
- Mondraker double butted 6061 alloy, rise: 12mm, width: 780mm, 9º backsweep, 5º upsweep, 31.8mm barbore
- Grips
- Onoff Diamond, 1lock-on, 130mm
- Seatpost
- Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L/XL size: 425x150mm
- Saddle
- SDG Fly MTN, PU foam, steel rail, Cordura sides
- Front brake
- Sram Guide T, lightweight 4-piston dual-diameter caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Rear brake
- Sram Guide T, lightweight 4-piston dual-diameter caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Brake lever
- Sram Guide T, tooled reach adjust
- Rim
- DT Swiss E1900 Spline 29, 30mm internal width, tubeless ready, 28 spokes
- Spokes
- DT Champion, straight pull
- Front hub
- DT 370, 15x110mm, IS 6 bolts
- Rear hub
- DT 370, 12x148mm, IS 6 bolts
- Front tyre
- Maxxis Minion DHR II 29x2.4 WT, Tubeless ready, 3C MAXX TERRA compound, Exo protection, 60TPI, folding bead
- Rear tyre
- Maxxis Aggressor 29x2.3, Tubeless ready, dual compound, Exo protection, 60TPI, folding bead
- Crank
- New Sram Eagle DUB Boost DM32t
- Rings
- 32T, CNC-machined alloy, X-SYNC 2
- Bottom bracket
- Sram DUB BSA, sealed bearings, 73mm
- Pedals
- /
- Chain
- New Sram Eagle, 12s
- Front derailleur
- /
- Rear derailleur
- New Sram NX Eagle -Horizon Type3 1x12s
- Lever
- New Sram Eagle Trigger right 12s
- Sprocket
- New Sram Eagle
- Hanger
- Mondraker M068
- Others
- *Optional Geometry kit: steering cups: +/- 1º
