CHRONO 2022

על המוצר

• Frame
• Chrono 29 6061 Xtralite Alloy butted, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle
• Sizes
• S: 395mm / M: 430mm / L: 470mm / XL: 520mm
• Fork
• RockShox Judy Silver TK 29, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 46mm offset. Settings: Poplock 2 pos remote compression (open/lock), rebound, air preload
• Headset
• ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
• Fork remote
• RockShox PopLoc
• Stem
• ONOFF Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S/M: 60mm, size L: 80mm, size XL: 90mm
• Handlebar
• ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore
• Grips
• ONOFF Diamond, 1lock-on, 135mm
• Seatpost
• ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm
• Saddle
• Mondraker XC Series, steel rail
• Front brake
• SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Rear brake
• SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Brake lever
• SRAM Level, tooled reach adjust, lever pivot bushings
• Rims
• MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes
• Spokes
• CN round stainless steel
• Front hub
• Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
• Rear hub
• Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts, MS freehub
• Front tire
• Maxxis Ikon 29x2.20, 60TPI, wire bead
• Rear tire
• Maxxis Ikon 29x2.20, 60TPI, wire bead
• Crankset
• SRAM SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
• Rings
• 34T, steel, X-Sync 2
• Bottom bracket
• SRAM DUB BSA, sealed bearings, 73mm
• Chain
• SRAM SX Eagle, 12s, Powerlock
• Rear derrailleur
• SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
• Shift levers
• SRAM Trigger SX Eagle, 12s, X-Actuation 1:1
• Casette
• SRAM PG-1210, 11-50T, 12s
• Derailleur hanger
• Mondraker M068
• Weight
• 12.9 kg
