CHRONO CARBON RR 2022

על המוצר

• Frame
• Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, Comfort Flat chainstays (Flatstays) design
• Sizes
• S: 395mm / M: 430mm / L: 470mm / XL: 520mm
• Fork
• Rockshox SID SL Ultimate RL 29, 100mm, Charger Race day, Debonair, tapered steerer tube, Boost 15x110mm axle, 32mm aluminum stanchions, offset 44mm. Settings: OneLock 2 position remote compression (open/lock), low-speed rebound, air preload
• Headset
• ONOFF Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º
• Fork remote
• RockShox OneLoc
• Stem
• MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: size S: 60mm, size M: 70mm, size L: 80mm, size XL: 90mm
• Handlebar
• ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore
• Grips
• ONOFF Diamond, 1lock-on, 135mm
• Seatpost
• ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm
• Saddle
• Mondraker XC Series, steel rail
• Front brake
• SRAM Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Rear brake
• SRAM Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Brake lever
• SRAM Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
• Rims
• Mavic Crossmax SL S 29, 25mm internal width, Maxtal welded rim, hookless, tubeless, 24 spokes
• Spokes
• Mavic straightpull duble butted, contactless lacing
• Front hub
• Mavic, Boost 15x110mm, IS 6 bolts
• Rear hub
• Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
• Front tire
• Maxxis Ikon 29x2.20, 3C MAXX SPEED compound, tubeless ready, 120TPI, folding bead
• Rear tire
• Maxxis Ikon 29x2.20, 3C MAXX SPEED compound, tubeless ready, 120TPI, folding bead
• Crankset
• SRAM GX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
• Rings
• 34T, CNC-machined alloy, X-SYNC 2
• Bottom bracket
• SRAM DUB BSA, sealed bearings, 73mm
• Chain
• SRAM SX Eagle, 12s, Powerlock
• Rear derrailleur
• SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
• Shift levers
• SRAM Trigger NX Eagle, 12s, X-Actuation 1:1
• Casette
• SRAM PG-1230, 11-50T, 12s
